Stageline SL100 Mobile Stage Rental

by Stageline
Price $2,900.00

STAGELINE SL100 MOBILE STAGE RENTAL - CALL FOR PRICE

Price based on location, date, duration.

Stageline SL100 mobile stage.  The only all-aluminium mobile unit featuring a fully hydraulic stage set-up. This ultra portable stage offers a total rigging capacity of 6,500 lb (2,948 kg) and strong enough to raise the roof loaded with 3,800 lb (1,725 kg) of sound, lights, banners and sets. Multiple deck configurations ranging from band-shell to a full professional-sized stage.

This mobile stage system includes the sound wings and cantilevers on each side of the stage to fly the sound system, as well as wind walls and banner bars for convenient and practical placement of banners.

STEP 1
Mobile Stage Truck - NY, NJ, CT, PA

Level the trailer and lower the floor panels. Easy hydraulic operations.

STEP 2
Mobile Stage Truck - NY, NJ, CT, PA

Install sound, lighting equipment and banners at ground level. Attach up to 3,800 lb to standard 2" tube trussing in roof (1,725 kg to 50 mm tubing)

STEP 3
Mobile Stage Truck - NY, NJ, CT, PA

Raise the roof using the hydraulic double-mast lifting mechanism.



We also offer banner placement, as well as banner printing services...


Banner Dimensions:

Banner Ad - Top = 36'-9" x 3'-8"
Banner Ad - Left = 6' x 16'
Banner Ad - Right = 6' x 16'
Banner Ad - Back = 23'-6" x 12'-8"

* Grommets every 12in (top & bottom) are recommended.





Technical specifications

Trailer
Length

31' 4 " - 34' 9"

9.55 m - 10.59 m

Width

8'

2.4 m

Height

11' 2"

3.39 m

Storage space **

23' 6" x 5' 9" x 5' 8"

7.2 m x 1.8 m x 1.7 m

Storage Compartment

18" x 18" x 16"

0.46 x 0.45 x 0.41 m

Storage space capacity **

5,000 lb

2,268 kg

Weight

9,990 lb

4,531 kg

Stage Floor
Length and Depth

24' x 20'

7.3 x 6.1 m

Length and Depth with Extension Platforms

40' x 24'

12.2 x 7.3 m

Height

3' 6" to 4' 3"

1.07 to 1.30 m

Design Live Load

100 lb/ft2

490 kg/m2

Type of Surface

Plywood on aluminium

Roof
Length and Depth

24' 11" x 23' 9"

7.59 x 7.23 m

Clearance (Inclined roof)

13' 9" to 14' 7"

4.22 to 4.45 m

Maximum Height with Banner*

23' 8"

7.21 m

Type of Surace

Fibreglass bonded on aluminium

Roof Lifting Capacity

3,800 lb

1,725 kg

Roof Load Bearing Capacity

6,500 lb

2,948 kg

4 Built in Rigging Points

350 lb each

160 kg each

2 Trusses - Upstage and Downstage (T2)

500 lb

227 kg

2 Trusses - Central Roof (T1)

700 lb each

320 kg each

2 Front Overhang Extensions - 9' 10" (3 m)*

250 lb at 34" each

113 kg at 0.86 m each

2 Side Overhang Beams

800 lb at 36" each

363 kg at 0.9 m each

Practical Aspects
Installation Time Once Levelling Complete

30 minutes - Less without windwall

Personnel Required

1 Certified technician and 1 stagehand

Site Preparation

None

Heavy Machinery Required

None

Mode of Transportation

1 Pick-up truck or fifth-wheel tractor*

Gust Wind Resistance

60 mph (97 km/h) with windwall or 80 mph (129 km/h) without windwall

Promotional Visibility*

Rolling billboard, multiple banner options

Rigging Bars*

Retractable, can be loaded from ground or stage level

Windwall*

Weatherproof - fire retardant vinyl or scrim (blow-through material)

Vertical and Horizontal Banner Supports*

Installed at ground level, close to 340 ft2 (31.6 m2) of promotional space

Floor Extension Platforms*

Integrated brackets - easy to install


* Offered in option.
** For optional stage related components (Extension platforms, barricades, ...)
